KMS RH

KMS RH

DOSING PUMP

Solenoid-driven metering pump KMS RH is the perfect solution for medium dosage need.

Foot mounted, it is equipped with backlit LCD display, microprocessor technology and manual stroke length adjustment. All liquid ends are in PVDF, but pump head and accessories in PP and hose in PE are available on request. Pump head is available with manual or self venting.

KMS RH, with proportional dosing system, has level control, stand-by input and ORP meter (supplied without ORP probe).

FEATURES

• Foot mounted
• LCD display
• Microprocessor technology
• Manual stroke length adjustment
• All liquid ends (pump head – injection valve – foot filter – delivery hose) are in PVDF
• PVDF pump head

FUNCTIONS

• ORP meter (0-2000mV) – supplied without ORP probe

EQUIPMENT

Dosage Proportional

Level control

Stand-by input

Alarm output optional

FLOW

Manual venting

bar	l/h	cc/S
20	1	0.1
18	2	0.19
15	4	0.37
10	5	0.46
8	8	0.74
5	10	0.93
5	1	0.09
2	18	1.67

Self venting

bar	l/h	cc/S
18	1	0.1
15	3	0.28
10	3.5	0.32
10	0.5	0.05
8	5.5	0.51
5	7.5	0.69
2	13	1.2

PUMP HEADS

• PVDF
• PP
• SS
• PMMA

ACCESSORIES

• PVDF injection valve
• PVDF foot/filter valve
• 2 m PVDF delivery hose
• 2 m flexible PVC suction hose
• 2 m PVC outgassing hose

CERTIFICATE
