K PLUS

CONSTANT/PROPORTIONAL DOSING SYSTEM

K PLUS

DOSING PUMP

Solenoid-driven metering pump K PLUS is the perfect solution for medium dosage need.
Foot mounted, it is equipped with microprocessor technology and manual stroke length adjustment. All liquid ends are in PVDF, but pump head and accessories in PP and hose in PE are available on request.

Pump head is available with manual or self venting.

K PLUS, with constant/proportional dosing system, has level control, digital signal, current signal and the following working modes: constant/constant with 1-10 divider, 1-10 pulses multiplier, 1-10 pulses divider, 10-100 pulses divider, 100-1000 pulses divider and mA current signal (0/4 mA = 0 pulses: 20mA=max pulses).

FEATURES

  • Foot mounted
  • Microprocessor technology
  • Manual stroke length adjustment
  • All liquid ends (pump head – injection valve – foot filter – delivery hose) are in PVDF
  • PVDF pump head

FUNCTIONS

  • Working modes: constant / constant with 1-10 divider – 1-10 pulses multiplier – 1-10 pulses divider – 10-100 pulses divider – 100-1000 pulses divider – mA current signal (0/4 mA = 0 pulses: 20mA = max pulses)

EQUIPMENT

Dosage Costant e Proportional

Level control

Stroke speed adjustment 0-1% e 0-10% e 0-100%

Alarm output optional

Current signal

Digital signal

FLOW

Manual venting

bar l/h cc/S
20 1 0.1
18 2 0.19
15 4 0.37
10 5 0.46
8 8 0.74
5 10 0.93
5 1 0.09
2 18 1.67

Self venting

bar l/h cc/S
18 1 0.1
15 3 0.28
10 3.5 0.32
10 0.5 0.05
8 5.5 0.51
5 7.5 0.69
2 13 1.2

PUMP HEADS

  • PVDF
  • PP
  • SS
  • PMMA

ACCESSORIES

  • PVDF injection valve
  • PVDF foot/filter valve
  • 2 m PVDF delivery hose
  • 2 m flexible PVC suction hose
  • 2 m PVC outgassing hose

K PLUS
